Automotive Toggle Switch

Name: Automotive Toggle Switch
Brand: Garg Overseas
Price: 100 INR
Availability: InStock

Price 100 INR/ Number

Get a Price/Quote

Automotive Toggle Switch Specification

Shape
Lever/Toggle

Size
Standard

Feature
Durable, Easy Installation

Shade
Black/Silver

Voltage
12V DC

Connector Type
Solder Lug

Vehicle Model
Universal Fitment

Weight
Approx. 18g

Pin
2 or 3 Pin

Insulation Resistance
100 M at 500V DC

Contact Form
SPST (Single Pole Single Throw)

Connection
Panel Mount

Used For
Automobile Electrical Circuits

Components
Toggle Lever, Spring, Mounting Nut, Terminal Pins

Color
Black Handle with Silver Body

Features
Robust Construction, Corrosion Resistant

Product Type
Automotive Toggle Switch

Style
Toggle

Operating Temperature
-20C to +70C

Power
Up to 20A

Contact Material
Silver Alloy

IP Rating
IP2X

Material
Metal and Plastic

Switch Action
On-Off

Electrical Life
10,000 cycles min.

Mounting Hole Diameter
12mm

Storage Temperature
-40°C to +80°C

Dielectric Strength
1500V AC for 1 minute

Mechanical Life
50,000 cycles min.

Panel Thickness Support
Up to 6mm

Terminal Type
Screw or Solder

Maximum Current Rating
20A @ 12V DC

Automotive Toggle Switch Trade Information

Minimum Order Quantity
100 Number

FOB Port
D

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque, Letter of Credit at Sight (Sight L/C), Western Union, Letter of Credit (L/C)

Supply Ability
1000 Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
If order is confirmed we will reimburse the sample cost

Packaging Details
CORRUGATED BOX

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
MSME

About Automotive Toggle Switch

Product Details :

Type : Automotive Toggle Switch

Material : Metal, Plastic

Usage: Automotive

Color : Black

Condition : New

Country of Origin : India

Pole : Single Pole

Features:

Sturdy

Durable

Reliable

Excellent quality.

Superior Electrical Performance

Designed to handle demanding environments, this switch offers a maximum current rating of 20A at 12V DC, with excellent insulation resistance of at least 100 megaohms at 500V DC. Its strong dielectric strength assures safety and longevity during operation, making it apt for automotive applications requiring high reliability.

Engineered for Durability

The switch features a robust combination of metal and plastic, and offers corrosion-resistant properties. Its mechanical life extends beyond 50,000 cycles and electrical life reaches at least 10,000 cycles, ensuring consistent performance. The lever action and sturdy construction also contribute to its long-term reliability in daily use.

Simple Universal Installation

Installation is quick and flexible thanks to the 12mm mounting hole and support for panel thicknesses up to 6mm. Compatible with both screw and solder terminal types, it accommodates various wiring preferences. Its standard size and universal vehicle compatibility allow dealers, exporters, and retailers across India to integrate it seamlessly.

FAQ's of Automotive Toggle Switch:

Q: How do I properly install the automotive toggle switch in my vehicle?

A: Begin by drilling a 12mm hole into a panel with a thickness of up to 6mm. Secure the switch using the mounting nut. Connect your wires using either the screw or solder terminal, depending on your preference. Ensure all connections are properly insulated, then fit the switch snugly into the panel for optimal performance.

Q: What makes this toggle switch suitable for automotive use?

A: This switch is designed with robust metal and plastic components, offering a maximum current capacity of 20A at 12V DC. Its IP2X rating ensures basic dust protection, while the high dielectric strength and durable mechanical construction make it ideal for the demands of automobile electrical circuits.

Q: When should I consider replacing the toggle switch?

A: It is recommended to replace the switch once it has surpassed its mechanical life of 50,000 cycles or its electrical life of 10,000 cycles. Signs of wear, unresponsive action, or visible corrosion on the terminals also indicate it is time for a replacement to maintain electrical safety.

Q: Where can this automotive toggle switch be used?

A: The toggle switch features universal vehicle fitment, making it compatible with a wide range of automotive models. It is commonly used in cars, trucks, and other motor vehicles to control auxiliary lights, accessories, or power circuits in both commercial and personal vehicles.

Q: What is the benefit of SPST (Single Pole Single Throw) contact form in this switch?

A: The SPST contact form offers straightforward on-off functionality, which simplifies wiring and operation. It ensures reliable switching of circuits in automotive applications, making it easy for users to control electrical accessories with a simple lever action.

Q: How does the toggle switch resist corrosion and maintain durability?

A: Constructed with corrosion-resistant materials like metal and plastic, and featuring a silver alloy contact, the switch is engineered to withstand harsh automotive environments. This robust construction promotes long-term performance and reduces maintenance needs, even in varying temperatures ranging from -40C to +80C.
